R290 Air To Water Heat Pump

R290 air to water heat pump R290 Air-to-water heat pump uses a full DC variable frequency Mitsubishi compressor, which has the advantages of a full DC variable frequency system with small vibration and low noise. It can operate efficiently and stably in extreme weather of -25°C. The maximum...

Send Inquiry

Product Introduction Product Parameters

R290 air to water heat pump

R290 Air-to-water heat pump uses a full DC variable frequency Mitsubishi compressor, which has the advantages of a full DC variable frequency system with small vibration and low noise. It can operate efficiently and stably in extreme weather of -25°C. The maximum outlet water temperature of the unit is up to 70°C

Powerworld R290 heat pump

This R290 heat pump uses an integrated waterway system configuration to facilitate customer installation and reduce the difficulty of installation operations. The control panel is embedded in the internal machine to facilitate customer operation. The internal machine is fully functional and can also be configured with a hot water tank and solar energy according to customer needs Coil.

Function
1. Built-in WIFI module, IOT platform;
2. Available in multiple languages;
3. SG smart grid function;
4. Dual temperature zone control is possible;
5. Remote upgrade function;
6. There are multiple modes to choose from, such as powerful, energy-saving, standard, and automatic.

Performance advantages:
1. Full DC frequency conversion Mitsubishi compressor, an internationally renowned brand, has small compressor vibration and low noise. It has a full DC frequency conversion system and can operate efficiently and stably in extremely cold weather of -25°C. The maximum outlet water temperature of the unit is as high as 70°C;
2. High-efficiency plate heat exchanger, reverse heat exchange between fluorine and water;
3. Full DC brushless variable frequency motor with large air volume, low noise, and stepless speed regulation;
4. Intelligent detection of temperature and pressure to provide effective safety protection for the unit;
5. Intelligent and efficient defrosting design;
6. Efficient and environmentally friendly R290 refrigerant;
7. The machine's energy efficiency reaches A+++, and its SCOP reaches 4.7.

Hot Tags: r290 air to water heat pump, air to water heat pump cooling, central split system heat pump, Monobloc Heating Air To Water Heat Pump, heating cooling heat pump, dhw heat pump, Commercial Heat Pump R290

Model	PW030-DKZLRS-E1/S(ODU)	PW040-DKZLRS-E1/S(ODU)	PW050-DKZLRS-E1(ODU)	PW055-DKZLRS-E1(ODU)
Heating Condition - Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out)：30/35℃
Heating Capacity Range (kW)	3.3~8.3	4.5~11.4	5.9~14.8	7.2~18.2
Heating Power Input Range(kW)	0.64~2.07	0.85~2.85	1.13~3.69	1.38~4.54
COP Range	4.01~5.17	4.00~5.29	4.01~5.22	4.01~5.22
DHW Condition-Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out)：15/55℃
Heating Capacity Range (kW)	3.7~7.4	5.2~10.2	6.6~13.2	7.5~16.8
Heating Power Input Range(kW)	0.79~2.10	1.10~2.87	1.41~3.73	1.61~4.79
COP Range	3.52~4.69	3.55~4.71	3.54~4.67	3.51~4.66
Heated water output (L/H)	159	219	283	361
Cooling Condition - Ambient Temp. (DB/WB):35/24℃,Water Temp.(In/Out)：12/7℃
Cooling Capacity Range (kW)	2.4~5.8	3.3~8.2	4.3~10.8	5.6~14.1
Cooling Power Input Range(kW)	0.79~2.19	1.08~3.28	1.39~4.15	1.80~5.38
EER Range	2.65~3.04	2.50~3.06	2.60~3.10	2.62~3.11
Power supply	230V/1Ph/50Hz/60Hz		380V/3Ph/50-60Hz
Diameter of pipe (mm)	DN25	DN25	DN25	DN25
Noise dB(A)	≤47	≤50	≤52	≤53
Net Weight (kg)	105	116	130	166
Body size(WDH) (mm)	1080×460×820	1080×460×960	1080×480×1060	1080×480×1372
Packing size(WDH)(carton)	1100×490×960	1100×490×1110	1100×490×1210	1100×490×1510
Packing size(WDH)(Polywood)	1140×520×974	1140×520×1120	1140×520×1220	1140×520×1520
Loading quantity (carton)	48/96	48/96	24/96	24/48
Loading quantity (Polywood)	44/88	44/88	22/88	22/44
IP Grade (Level of protection)	IPX4	IPX4	IPX4	IPX4
Anti-electric shock Rate	I	I	I	I
Operation Ambient Temp. (℃)	-25~43℃
Operating water temperature (℃)	20~65℃(DHW )
Operating water temperature (℃)	20~70℃(Heating)
Operating water temperature (℃)	7~35℃(Cooling)
