One System, Three Solutions
Heat ● Cool ● Hot Water
Experience total home comfort with a single, efficient system that delivers heating, cooling, and domestic hot water.
Full DC Inverter Technology
It perfectly combines eco-friendly R290 refrigerant and inverter technology to produce efficient house heating/cooling and hot water even under -25℃ extreme cold climate.
A+++ High Energy Efficiency
Achieves the highest energy level A+++ at both 35℃ and 55℃, and and a high heating EER of >4.5, ensuring optimal efficiency across varying conditions.
Instant Hot Water, No Waiting
Supports immediate heating, our heat pump delivers hot water instantly upon activation, eliminating cold delays while supporting outlet temperatures up to 75℃ for seamless compatibility with diverse heating systems.
Performs stably in environments ranging from -25°C to 43°C, ensuring year-round operation even in low-temperature environments.
Freeze-proof chassis heating prevents condensation ice buildup, ensuring reliable winter operation
AI Intelligent Defrost Technology
Equipped with AI-powered defrost technology, our heat pump automatically detects frost buildup and initiates intelligent four-way valve reversal for rapid, efficient defrosting. By integrating multi-point temperature and timing control, it significantly reduces defrost duration while maximizing energy efficiency and heating stability.
Two-Level Refrigerant Leakage Protection
Two-Level design keeps refrigerant out of indoor areas for complete safety.
Leakage Sensor ：Alarms at 15% LFL , automatically stopping key components while maintaining minimal ventilation.
Microbubble Exhaust Valve: Automatically vents refrigerant that leaks into the water circuit, preventing it from entering the room and ensuring operational safety.
Noise Lower to 35 dB(A)
5 Stage Noise Reduction
Achieve whisper-quiet comfort with our advanced 5-stage noise control system, Our heat pump delivers exceptional silent operation as low as 35 dB(A).
Fully Enclosed Compressor Space with PU Wave-Absorbing Cotton
TTriple-layer PU sound-absorbing cotton on sheet metal for superior noise reduction.
Intelligent multi-speed fan control adapts to ambient temperature
Large-angle 3D axial flow fan blades for smooth, quiet airflow
Two-stage silent mode for day/night operation flexibility
§14a EnWG Grid-Compliant Operation
Automatically limits power draw to 14A during peak hours, ensuring full compliance with German grid regulations.
Prevents Grid Overload: Supports community grid stability by avoiding peak-time strain.
Avoids Shutdowns: Ensures continuous operation without triggering safety cut-offs.
Cost Control： Protects from peak-time tariffs.
Seamless & Automatic: Intelligent power management requires no user intervention.
Intelligent 7-Inch Touchscreen Controller
Command your heating and cooling system with elegance and ease through our expansive 7-inch high-end capacitive touchscreen. Designed for a superior user experience, it features a beautifully intuitive interface (UI) that puts comprehensive control at your fingertips.
- Multi-Unit Control: Seamlessly manage up to 8 cascaded units with independent three-zone temperature control.
- Smart Connectivity: BMS (Modbus) integration, PV-ready, and external heat source control.
- Data Insights: Track energy use, heating output, and export history.
- Custom Automation: Holiday mode, timers, sanitization, and power limits.
Smart Temperature Curve Control
Select a pre-set curve and let the system do the rest. It automatically adjusts the water temperature based on real-time outdoor conditions, eliminating the need for manual setting changes.
• 8 Pre-set & 1 Custom Curve for heating and cooling
• Auto-Adjusts target water temperature
• Perfect Fit for any local climate
Smart Control, Smart Home
Smart Life/Tuya Smart App
WlFl remote control. Simple operation, easily check or control your heat pump from anywhere!
- Mode switching
- Energy consumption monitor and manage
- Real-time monitoring
- History record
- 15 Languages available
- Automatic fault diagnosis
- Various timing settings
- Operating parameters
Smart loT Cloud Control
Realtime monitoring, data operation and maintenance, saving time and costs for users, dealers, and manufacturers.
Communication method: WIFI and DTU
For detailed function display, please log in or view the manual.
- BIG DATA MANAGEMENT:Global device data collection,statistics, analysis and management.
- EQUIPMENT MANAGEMENT:Information statistics/ operation status /parameter viewing and setting / fault diagnosis report / operation log, etc.
- OTA UPGRADE:Quickly fix code defects and remotely iteratively upgrade product mainboards.
