1STABLE AND RELIABLE OPERATE AT -25℃
Under low ambient temperatures, the performance, heating ability, and operational stability of normal heat pumps will be limited. Power World's R290 full DC inverter heat pump can operate stably and efficiently in extremely cold regions of -25°C without EVI technology, maintaining a high COP and outputting 75°C hot water to ensure the heating and cooling of the house need.
Specification：
| Model | PW030-DKZLRS-E/S | PW040-DKZLRS-E/S | PW050-DKZLRS-E/S | PW050-DKZLRS-E | PW060-DKZLRS-E | |
| Heating Condition - Ambient Temp. (DB/WB): 7/6℃， Water Temp. (In/Out):30/35℃ | ||||||
| Heating Capacity Range (kW) | 3.3~8.3 | 4.5~11.4 | 5.9~14.8 | 5.9~14.8 | 8.8~22.0 | |
| Heating Power Input Range(kW) | 0.64~2.18 | 0.85~2.95 | 1.13~3.83 | 1.13~3.83 | 1.68~5.77 | |
| COP Range | 3.81~5.17 | 3.86~5.29 | 3.86~5.22 | 3.86~5.22 | 3.81~5.24 | |
| DHW Condition-Ambient Temp. (DB/WB): 7/6℃， Water Temp. (In/Out):15/55℃ | ||||||
| Heating Capacity Range (kW) | 3.7~7.4 | 5.2~10.2 | 6.6~13.2 | 6.6~13.2 | 7.8~17.6 | |
| Heating Power Input Range(kW) | 0.79~2.10 | 1.10~2.87 | 1.41~3.73 | 1.41~3.73 | 1.67~5.01 | |
| COP Range | 3.52~4.69 | 3.55~4.71 | 3.54~4.67 | 3.54~4.67 | 3.51~4.66 | |
| Heated water output (L/H) | 159 | 219 | 283 | 283 | 377 | |
| Cooling Condition - Ambient Temp. (DB/WB):35/24℃，Water Temp.(In/Out):12/7℃ | ||||||
| Cooling Capacity Range (kW) | 2.4~5.8 | 3.3~8.2 | 4.3~10.8 | 4.3~10.8 | 6.2~15.3 | |
| Cooling Power Input Range(kW) | 0.79~2.19 | 1.08~3.07 | 1.39~3.99 | 1.39~3.99 | 1.99~5.60 | |
| EER Range | 2.65~3.04 | 2.67~3.06 | 2.71~3.10 | 2.71~3.10 | 2.73~3.12 | |
| Space Heating (According to EN14825:2022) Average Climate Water Outlet 35°C |
Rated heat output (kW) | 6.0 | 8.0 | 10.0 | 10.0 | 14.0 |
| Seasonal Space Heating Energy Efficiency (SCOP) | 4.64 | 4.70 | 4.65 | 4.60 | 4.69 | |
| ErP Level | A+++ | A+++ | A+++ | A+++ | A+++ | |
| Sound pressure level (dB(A)) at 1 meter | 44 | 43 | 45 | 44 | 45 | |
| Space Heating (According to EN14825:2022) Average Climate Water Outlet 55°C |
Rated heat output (kW) | 6.0 | 9.0 | 9.0 | 12.0 | 13.0 |
| Seasonal Space Heating Energy Efficiency (SCOP) | 3.48 | 3.66 | 3.37 | 3.44 | 3.55 | |
| ErP Level | A++ | A++ | A++ | A++ | A++ | |
| Sound pressure level (dB(A)) at 1 meter | 44 | 47 | 46 | 45 | 46 | |
| Power supply | 230V/1Ph/50Hz/60Hz | 380V/3Ph/50-60Hz | ||||
| Diameter of pipe (mm) | DN25 | DN25 | DN25 | DN25 | DN25 | |
| Max water head(m) | 9 | 9 | 9 | 9 | 12 | |
| Net Weight (kg) | 112 | 120 | 138 | 138 | 170 | |
| Body size(W*D*H) (mm) | 1080×460×820 | 1080×460×960 | 1080×480×1060 | 1080×480×1060 | 1080×480×1372 | |
| Operation Ambient Temp. (℃) | -25~43℃ | |||||
| Operating water temperature (℃) | 20~65℃(DHW) | |||||
| Operating water temperature (℃) | 20~70℃(Heating) | |||||
| Operating water temperature (℃) | 7~35℃(Cooling) | |||||
