Under the Power World's elevated-temperature technology and EVI technology, this series of hot water heat pumps can run stably at an ambient temperature of -5°C~43°C, the outlet water temps up to 80°C, and the operating cost is low, which can meet the high-temperature water needs of slaughterhouses, electroplating plants, printing and dyeing plants, chemical, pharmaceutical, and aquaculture industries.
Copeland compressor, EVI technology.
Copeland scroll compressor, with EVI technology, supplements more capacity through economizer for high-temperature hot water outlet.
High-efficient tube in tube/ shell and tube heat exchanger.
Option for tube in a tube and shell & tube heat exchanger, high heat transfer efficiency, and easy maintenance for scales problem.
Drier-filter for a more reliable system.
Drier-filter removes possible dust and moisture in the refrigerant circuit, which ensures a more reliable and stable system.
Electronic expansion valve.
With accurate control of refrigerant flow automatically, excellent efficiency at different ambient temperatures.
Specification
|
Model |
PF030 -KFGRS-S |
PF030 -KFGRS |
PF050 -KFGRS |
PF100 -KFGRS |
PF150 -KFGRS |
PF200 -KFGRS |
PF250 -KFGRS |
PF300 -KFGRS |
|
Compressor Brand |
Copeland(EVI) |
|||||||
|
FouHMay valve Brand |
Sanhua |
|||||||
|
Expansion valve Brand |
Sanhua |
|||||||
|
Heating capacity (kW) |
7.4 |
8.3 |
13.8 |
27.6 |
41.1 |
55.1 |
65.3 |
82.6 |
|
Input power (KW) |
2.9 |
3.3 |
5.4 |
10.8 |
16 |
21.5 |
25.4 |
32.3 |
|
COP |
2.55 |
2.52 |
2.56 |
2.56 |
2.57 |
2.56 |
2.57 |
2.56 |
|
Rated current (#0 |
13.2 |
6.6 |
10.8 |
21.6 |
32.2 |
43 |
51 |
64.6 |
|
Max input power (kW) |
3.92 |
4.46 |
7.3 |
14.6 |
21.6 |
29.0 |
34.3 |
43.6 |
|
Max cunent (A) |
17.8 |
8.9 |
14.6 |
29.2 |
43.5 |
58.1 |
69.0 |
87.2 |
|
Rated outlet water temperature(℃) |
75 |
75 |
75 |
75 |
75 |
75 |
75 |
75 |
|
Highest outlet water temperature(℃) |
80 |
80 |
80 |
80 |
80 |
85 |
85 |
85 |
|
Power supply |
220V/5OHZ |
380V/50HZ |
||||||
|
Anti Electric shock Rate |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
|
IP Grade (Level of protection) |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
|
Refrigerant |
R134A |
|||||||
|
Operatkm Ambient IbmpfQ |
-5~43℃ |
|||||||
|
Production capacity (L/H) |
106 |
119 |
198 |
396 |
598 |
790 |
987 |
1184 |
|
Diameter of pipe (mm) |
Dn25 |
Dn25 |
Dn25 |
Dn32 |
Dn50 |
Dn50 |
Dn65 |
Dn65 |
|
water circulation (mYH) |
3 |
3 |
5 |
10 |
15 |
20 |
25 |
30 |
|
WMA pressure drop (kRa) |
25 |
25 |
30 |
35 |
38 |
46 |
48 |
52 |
|
Noise (dBfZ^) |
≤55 |
≤55 |
≤58 |
≤66 |
≤68 |
≤68 |
≤70 |
≤75 |
|
Net wesht/Gnoss we|ght(kg) |
105/111 |
105/111 |
150/160 |
310/330 |
372/412 |
482/532 |
582/642 |
612/675 |
|
Body size(W*D*H) |
1110*490*1260 |
1110*490*1260 |
1110*490*1260 |
1580*800*1600 |
1580*800*1600 |
1850*1000*1950 |
2000*1100*2080 |
2300*1100*2300 |
|
Loading quantity (2OGP/4OGP/4OHQ) |
28/56/56 |
28/56/56 |
12/24/52 |
6/12/12 |
6/12/12 |
6/12/12 |
4/10/10 |
0/0/5 |
|
Condenser type |
High-efficiency tank heat exchanger |
Casing heat exchanger | ||||||
|
Operating water temperature) |
9~80°c |
|||||||
|
Test condition |
Inlet water temperature 15℃, Outlet water temperature 75℃, Dry bulb temperature 20℃, Wet bulb temperature15℃. |
|||||||
