Commercial Heating Air Source Heat Pump

Name: Commercial Heating Air Source Heat Pump
Brand: Power World
SKU: 195381349

Series： Easylife Series
Power：8.4kw-35kw.
Function： Heating， Cooling, and Domestic hot water.
Energy Level：A+++.
Refrigerant：R32.
Noise (dB(A))：≤53.

Send Inquiry

Product Introduction Product Parameters

Among many kinds of refrigerants, R32 is one of the most concerned eco-friendly refrigerants at present. In the global market, due to the high heat transfer efficiency of R32, which can reduce power consumption by about 10%, the global warming potential (GWP) is low, and the impact on the environment is small, the heat pump air conditioner products are rapidly changing from R407C, R22, R410A transition to R32, it is one of the important energy alternatives solutions in the future market.

Products Feature

Approximately 10% reduction in electricity consumption

Compared with R410A, R32 uses 78% less refrigerant and can reduce carbon emissions by 68%

Higher Energy Efficiency Class A+++

The higher the energy efficiency class, the lower the energy consumption. One of the highlights of the Easylife Series DC inverter heat pumps is that its ERP (TUV) energy efficiency class reaches A+++ at 35C and A++ at 55C, and its SCOP is as high as 4.86, which means it can output the maximum heating capacity for the house with the minimum energy consumption.

LCD colorful Touchcream Multi-language Controller

Easylife series heat pump adopts a 4-inch super large LCD touchscreen controller with a clear letter display, sensitive touch response, simple operation, and complete functions.

a. Multiple Energy Saving Modes

It has four different operating modes: Power Mode, Silent Mode, Smart Mode, and Vacation Mode. Users can choose different operating modes according to their actual needs. This function can help users save unnecessary energy waste as much as possible while meeting the individual needs of users

b. 13 Different Interface Languages Displayed

As a product for the international market, the selection of multiple operating languages is essential, which allows users to easily read and operate Easylife Series heat pumps. There are 13 languages to choose from, such as English, Polish, Spanish, Czech, German, Danish, Swedish, etc. This multi-language function is incredibly convenient for users from different countries.

c. Support Rs485 and Modbus Communication Protocol

d. Support Linkage Control with Thermostat

The linkage switch inside the heat pump supports the connection with the indoor thermostat to achieve linkage control, and the temperature control can be accurate to ±0.1°C, making the indoor temperature more constant and comfortable.

Smart Home Solutions

The built-in WIFI module of this R290 heat pump can be directly connected to the “Smartlife” APP through the router. Users do not need to buy a WIFI module box, they can control the heat pump system and view the operating parameters of the unit anytime and anywhere through the smartphone.

Inverter Heat Pump

IoT Customer Management Platform

Power World's IoT cloud management platform can be connected with Wi-Fi or DUT to realize remote monitoring of data. This platform can record all the operating parameters of the units from Power World. If the unit has an error, the error report will be synchronized to the local service provider or Power World's console, and then we will quickly provide users with the best solution, which greatly saves the after-sales communication cost and time costs of users, dealers, and manufacturers.

Remote Control

Remote Monitoring

Remote Management

Hot Tags: commercial heating air source heat pump, R32 Split Heating and Cooling Heat Pump, R32 Multi Zone Heat Pumps, large commercial heat pumps, Multi-function Air Source Heat Pump, EVI Inverter Heat Pump, Industrial Monobloc Air Source Heat Pump

Specification：

Product model		PW030-DKZLRS-A	PW040-DKZLRS-A	PW050-DKZLRS-A	PW060-DKZLRS-A	PW080-DKZLRS-A	PW010-DKZLRS-A
Heating	Heating Capacity Range (kW)	1.57~8.40	4.40~13.00	5.9~18.2	7.5~23.0	10.2~28.0	12.8~35.0
	Heating input Range (kW)	0.32~1.87	0.90~3.02	1.20~4.11	1.53~5.23	2.07~6.36	2.61~7.99
	current Range (A)	1.42~8.30	1.39~4.68/ 4.12~13.8	1.86~6.37/ 5.49~18.8	2.37~8.11	3.70~11.4	4.67~14.3
	COP Range	4.49~4.91	4.30~4.90	4.43~4.92	4.40~4.90	4.40~4.92	4.38~4.90
Cooling	Cooling capacity Range (kW)	0.99~6.22	2.80~8.20	3.81~11.53	4.73~14.6	6.54~19.8	8.13~24.6
	Cooling input power(kW)	0.29~2.18	0.85~3.31	1.11~4.05	1.39~5.14	1.92~6.97	2.42~8.75
	current Range (A)	1.28~9.67	1.32~5.13/ 3.89~15.1	1.72~6.28/ 5.08~18.5	2.16~7.97	3.43~12.5	4.33~15.6
	EER Range	2.85~3.41	2.48~3.29	2.85~3.43	2.84~3.40	2.84~3.40	2.81~3.36
DHW	Heating capacity Range (kW)	1.28~6.81	3.52~10.50	4.80~14.72	6.1~18.5	12.3~20.4	13.6~22.6
	Heating input Range (kW)	0.31~2.13	0.88~3.39	1.17~4.60	1.53~5.97	2.8~5.37	3.09~5.95
	current Range (A)	1.38~9.45	1.36~5.26/ 4.03~15.5	1.82~7.15/ 5.35~21.1	2.37~9.26	5.0~9.6	5.52~10.6
	COP Range	3.2~4.1	3.1~4.0	3.2~4.1	3.1~4.0	3.8~4.4	3.8~4.4
Refrigerant		R32
Power supply		230V/1Ph/50-60Hz	230V/1Ph/50-60Hz / 380V/3Ph/50-60Hz	230V/1Ph/50-60Hz / 380V/3Ph/50-60Hz	380V/3Ph/50-60Hz
Working area	-30~43℃
Water circulation （m³/H）		1.4	2.2	3.1	4.0	4.8	6.0
Water pressure drop （kPa）		31	25	35	45	40	50
IP Grade (Level of protection)		IPX4	IPX4	IPX4	IPX4	IPX4	IPX4
Noise (dB(A))		≤53	≤55	≤57	≤58	≤62	≤66
Diameter of pipe (mm)		DN25	DN25	DN25	DN25	DN32	DN32
ERP Level (35°C)		A+++	A+++	A+++	A+++	A+++	A+++
Operating water temperature (℃) DHW	9~55℃
Operating water temperature (℃) heating	9~50℃
Operating water temperature (℃) cooling	7~35℃
Remark: Heating working condition: Inlet water temperature 30℃, Outlet water temperature 35℃, Dry bulb temperature 7℃, Wet bulb temperature6℃. Cooling working condition: Inlet water temperature 12℃, Outlet water temperature 7℃, Dry bulb temperature 35℃, Wet bulb temperature 24℃. DHW working condition: Inlet water temperature 15℃, Outlet water temperature 55℃, Dry bulb temperature 7℃, Wet bulb temperature 6℃.
